One of our ideas – cappriccio

inspired by Jan Svankmajer’s work.


The Cabinet of Jan Svankmajer 1987

Cappriccio is an Italia word, means based on imagination,close to the fantasia.

As you can see, We have a printer, a motor and a light from printer, and a few small stuff ( small sensors, small swifter , round rubber eraser )

So far, we have done the swifter to control the printer belt move.

My neighborhood and work Trash map

These are the basic areas where I am looking for salvageable stuff, havnt found much as of yet, A few power chargers and a noise machine.


Rube Goldberg Video!

Here’s a video of our machine operating!

Everything goes by super fast in the video, but to break things down here’s the flow:

1) The power gets activated. (Shown by pushing the ‘test’ button on the power supply)

2) Power activates the motor which sends the ink tray across the printer. Since the motor would normally keep trying to push the ink tray one direction, causing a nasty clicking sound, we installed a kill switch that the tray flicks as it passes which turns off the motor.

3) The ink tray knocks over part of the old printer’s power supply casing which is tied to a string, which is in turn tied to a lever. When the casing drops it pulls on the string with enough force to throw the lever.

4) The lever starts some gears in motion that drops the paper tray on the printer.

5) The paper tray is attached by a string which is tied to a camera lens. When the tray drops it pulls the lens’ zoom.

6) That lens has a small arm that extends and retracts when manipulated. We attached to wire leads to that arm, causing another circuit to be closed or opened depending on the lens’ state. When the string pulls the arm is retracted and the circuit closed, causing the scanner’s light bar to start moving.


Rube Goldberg Progress & Damange Report

Our group was able to get our hands on two old printers and had to do something with them. There wasn’t much electronics to work with so we decided to focus on the non-electronic mechanisms that we were able to trigger with what we have and to have fun! So this was what we were thinking:

This is how far we got today. Terese and I managed to get the top sliding part(the cartridge holders) to slide across, then smash into & turn on the switches, which then set the bottom part(paper feeder) going and shooting out pieces of paper bills. A needle was attached onto each cartridge holder on the inside so that when the holders smash inwards, the needles would also pop the balloon, making an explosion of confetti (tiny polystyrene foam balls). We didn’t take any videos cus all hands were on deck(holding wires or trying to hold something in place)…

 back – we powered both of the paper feeders on just one power source. We weren’t sure whether it will power also the top sliders and didn’t want anything to explode so used another power supply for the top part.

The magical part.

Everything was going fine and we were going to work on the finishing touches the next day and

This happened.

Due to intensive testings and aging of the band that runs on the gears & pulls my cartridge holder, BROKE
It was so bad that I wasn’t able to pull it back together…:(
Nor could I replace it because of THIS:

The pieces of loose string (that made up the band) were stuck and got tangled up with the gear.
You can tell how unhappy I was ‘cus I didn’t even feel like getting my camera out, haha

We were also thinking to attach a piece of rollable paper to the cartridge holder so that it unrolls and reveals the secret message when the cartridge holder slides inward & pulls. Also party poppers that goes off at set times when the slider goes across but it was impossible to find them?

It’s a major bummer but we’ll manage to figure something else out, hopefully, by Tuesday!
